Secure the lower leg section in a padded vice, or wrap in cloth to avoid scratching. This is the procedure that most will need to rectify seized sticks. The cam presses down in turn onto the retained head of a small diameter rod that passes all the way down through the top leg section to the locking piece at the end. Once out you can see the simple 'roller cam' arrangement fitted to the top of the leg that transfers the trigger movement to the internal leg release mechanism irrespective of the angle of the leg to the handle. The legs are disconnected from the handle by removing the housing cover and the 8mm pivot bolts. The screws will have paint/laquer in the heads, so make sure the tool gets in for a good fit. For access, invert the sticks and remove the 2mm hex head screws and housing cover. When the trigger is operated it presses the spindle down through the swivel section of the sticks onto a moveable plate in the housing that the legs are attached to. There is an adjustment within the handle for the trigger mechanism should you need to tighten up the travel - simply turn the knurled nut on the spindle. The trigger mechanism inside the handle can be easily accessed by undoing the 2.5mm hex screw that is visible from looking up underneath the handle, and then releasing the grip inert to the rear. Starting at the top, but if it's just seized legs that are the problem you can skip down a bit. The Gen II mono and tripod models will be similar in operation but may have more or less securing screws to the bottom cover plate. I have the Gen II bipod model so can't speak about the earlier ones. New Heavy Duty look with Dark Earth Accents.There are the original Primos sticks and the current Gen II models, which apparently differ in construction and operation.Backbone Strengthened Rotating Joint for Smooth Panning.NOTE: Keep in locked position at all times to assure yoke or optics are secure.New Quick Detach Yoke System with Integrated Lock.THE ONLY SHOOTING STICK WITH A QUICK AND EASY ONE-HAND ADJUSTMENTS.
The Primos Trigger Stick Gen 3 is the ultimate solution for making your shot accurate no matter where you go. The Extreme leg angles gives you the versatility of being able to set up quickly on any terrain from nearly any position. We have advanced our design by incorporating a Quick Detach Yoke System that allows for easy transitions from a shooting stick to a smooth panning support for optics or cameras. By far it is the quickest most effective way to get a rock solid shooting support. Our Patented Trigger Stick has been upgraded to perform even better. Now you’re ready to make the shot of a lifetime anytime, anywhere. Whether you’re sitting, kneeling or standing simply squeeze the trigger again for a last-second micro adjustment without losing your sight picture. It’s the only shooting stick that allows you to make quick and steady one-hand adjustments to get on the mark faster. The one on their rifle, and the one on their Trigger Stick from Primos. Ask any hunter whose livelihood depends on making big shots count and they’ll tell you they bring two triggers.
